Sealeds Night Watch 0Red/White
| Side pin: | +- |
| Back pin: | +- |
WE ACCEPT Payment by PAYPAL - easy way to do it!
| Number of LED: | 6 |
| LED type: | 5630 middle power |
| Brightness (lm): | 216 |
| Colour Temp: | 2700 Kelvin (super warm white) |
| Colour fidelity: | CRI >93, R9>50 |
| Operating Voltage: | DC 10-30V; AC 10-24V |
| Power Consumption: | max. 2,20 W |
| Current: | 0,17 A @ 12V / 0,08 A @ 24V |
| Base type: | G4 side or back pin |
| Effect on radio frequency: | no interferences |
| Beam angle: | 120' |
| Allowable operating Temp: | -10°C ... 50°C |
| Led life: | 50000 hours |
| Dimensions: | D30mm, H5,6 mm, pins length 30mm, on request available longer pin versions |
| Warranty: | 2 years |
| The driver has built-in: | protection features such as pulse by pulse current limit thermal sensing and shutdown due to excessive power dissipation. |
This is a sister module to the Dual Color Night Watch LED. It is a similar module as Red/White equipped with uC and software but without RED LEDs. If there is no need to have the whole section of lights to give red light, we use these modules to stay unlit at the first switch.
You mount one or two modules of Red/White Sealeds Dual and the rest 0Red/White Sealeds.
Procedure and algorithm remain the same. The result is different.
Once you switched ON whole sector only Dual will light their Red sections, after 3-4 seconds gentle blink of RED leds appears giving you a chance to switch OFF and ON again during 3-4 second (after blink) will result full light of all luminaries in section.
When SEALEDS Dual operate in night mode - Red, in the same time SEALEDs 0Red/White are in standby mode ( no light) use only 4,5mA which means the power consumption is below 55mW. Our marine led G4 bulbs do not interfere with RF equipment on board.
Dual color G4 LED bulbs - seaLEDs, are designed and manufactured in EU, (well) made in Poland.
